Longitudinal Section
1st Floor
2nd Floor Plan
DSC_0079
DSC_0107 2
Orr_Ryan_arch_3rdYr_2010

Maritime Museum Expansion: An Inundated Haven

developed for Self

While focusing on layers of occupied and unoccupied space, additional layers were found through the orientation of the building and wind turbines, by using wind patterns. The building creates a reminiscent feeling of an operating port with raised structures over head, and close proximity to the water. Surrounded by water, the building connects the wind and water through the building – providing views and experiences The materiality also suggests a notion of lightness as the structure breaks the five bars and turns to glass. The layers within the project allow for the visitor’s experience to change depending on where they are located within the project.

  • Client - Self
  • Date Completed - Fall 2010
  • Skills/Tools Used - Concept Design, Diagramatic Planning, Program Planning, Schematic Design, Partial Construction Documents, Physical Model Building
